SHARPEN YOUR PROFITS

Better, Faster, Professional Chain Sharpening


HOW FRANZEN WORKS

To purchase a Franzen machine or for further
information, contact your stens sales rep.

FRANZEN BENEFITS

MORE VOLUME

  • Turn-Key automated chain sharpening
  • Teeth and rakers
  • Plug & go set up (30 Seconds!)

MORE SATISFIED CUSTOMERS

  • Automatic tooth-detection & damaged/broken
  • Flawless,professional results

MORE PROFIT

  • Works tirelessly without supervision
  • Quick turnaround time helps you serve more customers

SAMPLE RETURN ON INVESTMENT

$19,200.00

Franzen Chainsaw Chain Sharpener MAKES YOU MONEY!

If you charge $8.00 per chain and sharpen 10 chains per day, that equals $80 per day.

240 days per year = $19,200.00 Franzen income per year!

PLUS manual chain sharpening labor can be used for other billable jobs while the Franzen does the sharpening!


FREQUENTLY ASKED QUESTIONS

How long does it take to sharpen a standard 18" chain?
3 - 4 minutes.


How long does it take to set up the machine?
Once the operator is comfortable with the machine, the setup can be done in less than one minute. Usually 30 seconds is all that is needed.


Does the machine sharpen both chain teeth and rakers?
Yes. During the same sharpening cycle, but chain teeth and rakers are sharpened. The Franzen SA6 also detects missing or damaged teeth and/or rakers and adjusts the sharpening cycle accordingly.


What is the longest chain you can sharpen with the machine?
Straight out of the box, the machine is capable of sharpening up to a 36" bar/chain (approximately 116 drive links). An additional attachment can be purchased to accommodate larger chains up to 8' (96").


Will the machine do any pitch chain?
The machine will do any pitch chain including ¼", .325" 3/8", ¾" (with attachment) and .404." It can also do skip link chain.


Will the angles can the chain be sharpened?
From 10° to 50° angles.


Does the machine do both left and right cutters in the same cycle?
Yes, the sensor head is made up of three hardened steel pieces. They will detect whether the tooth is a left or right by a difference of pressure on the sensor.


What about the depth gauge?
The machine can be set to do the depth gauge in the same cycle, or you can skip the depth gauge cycle if desired.


Will the machine do carbide tipped chains?
The machine will have no problem with carbide chains; however you will have to install a Diamond wheel. (A diamond wheel is not included in the sale of the Franzen)


How many stones come with the machine?
Nine grinding wheels are included: Three each of: large for .404" chain, medium for 3/8", small stone for .325" and ¼" chain. The machine also comes with two stones for the depth gauge.


How many sharpenings can you get out of each stone?
Depending on the cleanliness of the chain being sharpened, you can get anywhere from 400-600 sharpenings per stone.


Can you use Borazon wheels with the machine?
Yes, as long as the center hole of the wheel is machined to the proper size for the motor shaft.


What types of power requirements are needed for the machine?
The Franzen machine runs off 110V and at least 90-psi air pressure is needed.


How big is the machine and how much does it weigh?
Length - 26", Width - 26", Height - 75", Weight = 450 lbs.


What kind of maintenance is required?
The Franzen is maintenance free; there are no lubing points, or filters to change. We only recommend that you blow off the sensor head with air at the end of each day and occasionally replace the special abrasive wheels to ensure the machine is performing at its peak.


Who will train my staff on how to set-up and operate the machine?
Hands-on training by a Stens Franzen Specialist who will visit your facility to train your staff for locations in the 48 contiguous United States.


What kind of warranty does the machine have?
The Franzen Chain Sharpening Machine carries a 2 year limited warranty, with grinding motors covered under a one year warranty. Grinding wheels are excluded from warranty.


What types of people buy the Franzen?
Anyone who sharpens chains. Franzen customers include rental stores, tree trimming businesses, equipment repair shops. Many customers sell or service chainsaws, and many others do not sell or repair chainsaws.
